Gelgon FT
Gelgon FT
FT Filler / Polyester / Oval
The Gelgon FT is a water swellable polyester single-end yarn construction. The SAP coating is custom designed for Fil-Tec and applies with our proprietary process. The oval shape lends itself very well to fill the interstices between conductors. This is our economy version of our Gelgon FTW. For longitudinal and helical applications.
Features & Benefits
- For copper and aluminum power cables
- Our water blocking yarns are the best replacement to flooding compounds and powder SAP materials used by cable makers to water block the cable
- Virtual elimination of dust. Promotes a safer work environment by eliminating fugitive particles that can cause operator health concern and premature wearing of moving parts of the equipment
- Improves operating speeds when compared to the use of flooding compounds and electrostatically applied SAP
- Cables made using our Gelgon water blocking yarn solution pass the 15 minutes and one hour water penetration tests. They additionally pass the connector and aging tests (500 cycles)
- Extremely fast reaction speed when in contact with water. 80-85% of gel forms in the first minute
| Product | Base Denier | Yield Yd/Lb | Yield M/KG | Break (lbs) | Break (kg) | Absorption (g/g) | Profile |
|---|---|---|---|---|---|---|---|
| FT 6500 | 840 | 3225 | 6500 | 75 | Oval | ||
| FT 5000 | 1000 | 2358 | 5000 | 20.1 | 9.12 | 75 | Oval |
| FT 4200 | 1300 | 2084 | 4200 | 75 | Oval | ||
| FT 3600 | 1500 | 1792 | 3600 | 26.90 | 12.20 | 75 | Oval |
| FT 2610 | 2000 | 1295 | 2610 | 75 | Oval | ||
| FT 2600 | 2000 | 1280 | 2600 | 42.20 | 19.14 | 75 | Oval |
| FT 2000 | 2600 | 996 | 2000 | 53.9 | 24.45 | 75 | Oval |
| FT 1500 | 3600 | 722 | 1500 | 71.70 | 32.5 | 75 | Oval |
| FT 1400 | 2600 | 689 | 1400 | 45.00 | 20.41 | 100 | Oval |
| FT 1010 | 5200 | 497 | 1010 | 104.1 | 47.2 | 75 | Oval |
| FT 1000 | 5200 | 497 | 1000 | 94.5 | 42.86 | 75 | Oval |
| FT 800 | 6700 | 389 | 800 | 121.7 | 55.2 | 75 | Oval |
| FT 750 | 5200 | 373 | 750 | 94.5 | 42.86 | 100 | Oval |
| FT 700 | 7800 | 344 | 700 | 145.5 | 66.0 | 75 | Oval |
| FT 500 | 10400 | 249 | 500 | 194.0 | 88.0 | 75 | Oval |
| FT 350 | 15600 | 172 | 350 | 275.7 | 125.1 | 75 | Oval |
| FT 250 | 20800 | 124 | 250 | 367.6 | 166.7 | 75 | Oval |
